Brightness

• 10,000 ISO lumens
• 10,000 Center lumens
• 8,900 ANSI lumens

​Color wheel

• Built-in C/W Options: High Brightness C/W: 5 Segment (RGBYW), Rich Color C/W: 5 Segment (RGBYC)

Contrast (nominal)

• 2500:1 Full On/Off; 120:1 ANSI

Type

• 1-chip 0.96” DMD

Native resolution

• 1920 x 1200 (2,304,000 pixels) 16:10

Type

• 2 x 430W UHP

Typical lifetime

• 2000 hrs typical @ Normal Mode
• 4000 hrs typical @ ECO Mode
• 1000 hrs typical in Portrait Normal Mode

Standard

• HDMI x 2
• 3GSDI x 1 (BNC)
• DVI-D x 1 (Digital only)
• HD15 x 1 (RGBHV or component video)
• Composite Video x 1 (BNC)
• USB x 1 (type A) - Optional Wireless or PC-less
• HDBaseT (RJ45 x 1)

Signals

• HDTV formats VGA through to WUXGA (1920 x 1200)
• Horizontal and vertical scaling while maintaining aspect ratio, all inputs

Pixel clock

• 27-150MHz

Scan rates

• 525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60) 1125p(1080p@50/60)

Monitor out

• HD15 x 1

• RS232 In
• Control via HDBaseT
• Ethernet (10/100) RJ45 with ChristieNET connectivity
• Built-in Backlit Keypad
• Wired Remote Control (3.5mm stereo) - Loop out available for daisy chaining

Standard

• WW: 3 x 3m Power cord (US , Euro, UK) or China Model: 1 x 3m China, Ferrite core and band x 2, Cable Tie x 2
• RGB cable (2m)
• Adapter cover
• Wireless remote control / AA batteries x 2
• User’s manual CD including Safety Guide, Quick setup guide, Network quick setup guide, Operating guide, Network guide, Instant stack guide, Technical guide, Software license agreement x 1, User’s manual

Optional

• Replacement Hybrid Filter
• Optional Wireless Dongle (USB)

• Tool-free lens insertion system
• Boresight adjustable
• Motorized horizontal and vertical lens offset (Memory Available)
• Motorized zoom and focus adjustment (Memory Available)

Lenses

• 0.38:1 Ultra Short Throw Fixed Lens
• 0.8-1.0 extra short throw zoom
• 1.2-1.8/1.1-1.7 short throw zoom
• 1.7-2.5 standard zoom
• 2.5-3.8/2.4-3.6 middle throw zoom
• 3.6-5.8/3.7-5.9/3.5-5.6 long throw zoom
• 5.7-9.1/5.8-9.2/5.5-8.8 extra long throw zoom

Offsets 0.38:1 UST Lens

• Vertical Offset is fixed value which varies with image size: Reference UST calculator
• No Horizontal offset.

Offsets 0.8-1.0:1 Zoom Lens

• +105%/-50% Vertical
• +/- 22% Horizontal

Offsets all other lenses

• +125%/-50% Vertical
• +/- 22% Horizontal

Operating voltage

• 110 VAC to 240 VAC @ 50/60 Hz

Power consumption

• 1070W +/-10% (220V)
• 1090W +/-10% (110V)

Operating current

• 5.6A +/-10% (220V)
• 10.2A +/-10% (110V)

Dissipation

• 3720 BTU/hr max (110-120V)
• 3652 BTU/hr (220-240V)

• Typical: Normal Mode: 38dB(A), Eco Mode: 33dB(A)

Dimensions

• (L x W x H) 18.2 x 21.1 x 6.9" (463 x 537 x 174mm)

Weight (without lens)

• 38.6 lb (17.5 kg)

Shipping dimensions

• (L x W x H) 22.1 x 29.3 x 12.4" (561 x 743 x 315mm)

Shipping weight

• 50.7 lb (23.0 kg)

Temp: From sea level to 1,600m (5,249feet)

• Normal: 0 ~ 45 °C
• Eco: 0 ~ 50 °C

Temp: From 1,600m (5,249feet) to 3,048m (10,000feet)

• Normal/Eco: 0 ~ 40 °C

Humidity​

• ​10 - 80% non-condensing

This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC)

• FCC, Part 15, Subpart B, Class A
• EN55022/CISPR22 Class A
• ICES/NMB003 (A)
• EN55024 / CISPR24
• IEC 60950-1
• UL 60950-1
• EN 60950-1
• CAN/CSA C22.2 No. 60950-1
• Directive 2011/65/EU (RoHS)

Certifications marks (check with Christie for latest update)

• cULus (Canada & US)
• CE (EU)
• CCC (China)
• EAC/CU (Russia)
• RCM (Australia and New Zealand)
• BIS (India)
• NOM (Mexico)
• SASO (Saudi Arabia)
• SABS (South Africa)
• KC (Korea)
• Ukraine
• TER (Kuwait)

• 3 years parts and labor (including light engine)
• ​Contact an authorized Christie representative for full details of our limited warranty​
