Christie Boxer 4K20

Part Number: 144-011103-XX 4K, 20,000 lumens, 60Hz, 3DLP projector

Product characteristics

  • Native 4K resolution and processing for unmatched and uncompromised performance
  • 4K content maintains stunning color reproduction and image quality from input through to screen with Christie TruLife processing
  • Light stays on –multi-lamp design gives you confidence that you’ll always have light on your screen
  • Stay at full brightness – lamps can be replaced quickly and easily
  • Installation freedom – omnidirectional deployment capabilities for projecting images in any position
  • Built-in warp and blend functionality with Christie Twist
  • Flexible 4K – high bandwidth multi-input card (HBMIC) ​provides versatile 4K connectivity, with preview capability and fast syncing or switching between inputs as well as direct fiber input, when used with a Christie Link transmitter
  • Easy to manage – preview screen for at-a-glance status updates and integrated near field communication (NFC) for lamp information tracking even without AC applied
  • Simple to ship and handle – weighs only 160lbs

  • Description
  • Spec
  • Option
  • Download

Christie® Boxer 4K20 is a 20,000 lumen, 4K resolution, 3DLP® projector built for life on the road. Rugged and efficient with intelligent design and feedback, Christie Boxer 4K20 future proofs your fleet with considerable brightness and a low cost of ownership. It’s compact and easy to travel with at only 160lbs.

Featuring four Mercury lamps the Christie Boxer 4K20 provides 1,500 hours of lamp-life to 70% initial brightness. With the added benefits of single-phase power to reduce set-up cost and complexity, built-in warping and blending, omnidirectional installation options, and the widest range of connectivity on the market the Boxer 4K20 is sure to meet all your AV expectations. And with Christie TruLife™ electronics, the Christie Boxer 4K20 joins the Boxer Series family in creating powerful and inspiring visual experiences.

Features

  • Native 4K resolution and processing for unmatched and uncompromised performance
  • 4K content maintains stunning color reproduction and image quality from input through to screen with Christie TruLife processing
  • Light stays on –multi-lamp design gives you confidence that you’ll  always have light on your screen
  • Stay at full brightness – lamps can be replaced quickly and easily
  • Installation freedom – omnidirectional deployment capabilities for projecting images in any position
  • Built-in warp and blend functionality with Christie Twist
  • Flexible 4K  – high bandwidth multi-input card (HBMIC) ​provides versatile 4K connectivity, with preview capability and fast syncing or switching between inputs as well as  direct fiber input, when used with a Christie Link transmitter
  • Easy to manage – preview screen for at-a-glance status updates and integrated near field communication (NFC) for lamp information tracking even without AC applied
  • Simple to ship and handle – weighs only 160lbs

We’re here to support your investment

Backed by Christie's industry-leading warranties, service and support, you can feel confident investing in the Christie Boxer 4K20. If you have any questions, or if you’d like to speak to a Christie sales representative, please contact us.​

Brightness
  • 19,500 ANSI (typical)
  • 20,000 center
  • 22,000 ISO
Contrast
  • 2000:1
Display
  • 3DLP 1.38" DMD
Resolution
  • 4K (4096 x 2160)
Illumination
  • 4 x 450W NSH
Lamp life
  • 1500 hours to 70% initial brightness
Inputs
  • 1 x High Bandwidth Input Card (HBMIC)
    • 2 x 12G-SDI
    • 1 x HDMI 2.0
    • 1 x DisplayPort 1.2
    • 1 x Fiber (QSFP+) - For use with Christie Link Transmitter
Pixel clock
  • 1.2Gpx/s – Christie TruLife Electronics
Networking
  • Keypad
  • RS232 in
  • Ethernet (10/100) RJ45
Optional accessories
  • Dual link DVI input card
  • Twin HDMI input card
  • Dual 3G HD-SDI input card
  • Twin DisplayPort input card
  • Rigging and stacking frame
  • Quad DisplayPort input card (HB)
Lens mount
  • Tool-free lens insertion system
  • Boresight adjustable
  • Motorized horizontal and vertical lens offset
  • Motorized zoom and focus adjustment
Lens options

Fixed

  • 0.72:1 (no offset)
  • 0.9:1 (Offset: V: ±45%, H: ±18%)

Zoom

  • 1.13-1.31:1 (Offset: V: ±60%, H: 23%)
  • 1.31-1.63:1 (Offset: V: ±82%, H: 28%)
  • 1.63-2.17:1 (Offset: V: ±86%, H: 32%)
  • 1.98-2.71:1 (Offset: V: ±13%, H: 4%)
  • 2.71-3.89:1 (Offset: V: ±43%, H: 14%)
  • 3.89-5.43:1 (Offset: V: ±86%, H: 22%)
  • 5.43:1 -7.69:1 (Offset: V: ±56%, H: 19%)
Power
  • 200-240V
  • 19A
Dimensions
  • (L x W x H) • 37.75 x 23.5 x 12"
  • 959 x 597 x 305 mm
Weight
  • ~160lbs
Operating environment
  • Temperature: 5 to 40°C (41 to 104°F)
  • Humidity: 10 to 80%, non-condensing
Limited warranty 3 years
