| 프로젝션 방식 |
DLP |
| 기본 해상도 |
XGA (1024 x 768) |
| 밝기* |
5,000 ANSI Lumens |
| 명암비 |
5,000:1 |
| 디스플레이 색상 |
1.07 Billion Colors |
| 렌즈 |
F=2.45~3.07, f=15.78~25.12 |
| 투사율 |
1.41~2.25 |
| 선명한 이미지 크기 / 최대 이미지 크기 |
60"~240" |
| 줌 |
1.6X |
| 램프 (기본/Economic)* |
2,000/ 2,500 hours |
| 키스톤 보정 |
2D, Vertical & Horizontal ± 30 degrees |
| 프로젝션 옵셋 (Projection offset) |
107.5% ±2.5% |
| 해상도 지원 |
VGA (640 x 480) to UXGA (1600 x 1200) |
| 수평 주파수 |
15KHz~102KHz |
| 수직 주사율 |
24Hz~120Hz |
| 렌즈시프트기능 |
Vertical: +7.5% |
| 램프 소비전력 |
370W |
| 크기 |
411.4 x 118.4 x 267.5mm |
| HDTV 호환성 |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| 비디오 호환 |
NTSC, PAL, SECAM |
| 입력단자 |
Computer In (D-sub 15pin) x 1 (Share with component)
Monitor Out (D-sub 15pin) x 1
Composite Video In (RCA) x 1
S-Video In (Mini DIN 4pin) x 1
HDMI x 2 (One with MHL)
Audio In (Mini Jack) x 1
Audio L/R in (RCA) x 1
Audio Out (Mini Jack) x 1
Speaker 10W x 2
LAN (RJ45) x 1 (LAN Control)
USB (Type A) x 1 (5V/ 1.5A Power Supply)
RS232 (DB-9pin) x 1
DC 12V Trigger x 1
IR Receiver x 2 |
| 무게 |
4.9kg |
| 소음도 |
36/ 33 dBA (Normal/ Economic mode) |
| 자동전원공급 |
AC 100V to 240V, 50Hz to 60Hz |
| 소비전력 |
Typical 490W, Network Standby <6W, Stanby Power <0.5W |
| 전력 관리 기술 |
Automatic power off after 20 minutes without a display source |
| 다국어지원 |
Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages) |
| 이미지모드 |
Bright/ Presentation/ sRGB/ Cinema/ (3D)/ User 1/ User 2 |
| 액세서리(기본) |
Remote Control w/ Battery
Power Cord (by region)
User Manual CD
Quick Start Guide
Warranty Card (by region)
VGA (D-sub 15pin) Cable
|
| 액세서리(추가) |
Presentation Plus - P/N: 65.J9306.002
Spare Lamp Kit - P/N: 5J.JDP05.001
Ceilling Mount - P/N: 5J.JAM10.001
3D Glasses - P/N: 5J.J9H25.001
|
